Dingli 1412PA – 13.8m electric scissor lift
Dingli 1412PA – 13.8m electric scissor lift
Make an enquiry
Machine information
The Dingli 1412PA 13.8m electric scissor lift is suited for use on indoor jobs, including facilities management, warehousing and cold stores. It provides a maximum working height of 13.8m and a safe working load of 320kg. The lift features power to platform and an extendable platform that extends out to 3.17m for extra reach.
With a closed width of 1.19m and a closed height of 2.62m (which can be reduced to 2.09m by lowering the guardrails), the 1412PA provides excellent manoeuvrability in confined spaces.
Equipped with non-marking tyres and an electric drive system, the 1412PA functions efficiently, producing minimal noise and zero emissions, which makes it well-suited for urban settings. Additionally, its capability to be driven at full height enables consistent productivity throughout tasks. The 1412PA is a low energy consumption machine as the total transmission efficiency of the direct motor drive systems reaches 95%, promoting an energy saving in excess of 30% energy when compared with traditional hydraulic systems.
Furthermore, the 1412PA is an oil-free machine, employing electric actuators instead of hydraulic systems. This design removes the possibility of oil leakage and site contamination, making it particularly well-suited for deployment in environmentally sensitive locations.
Standard features
Battery powered
Maintenance-free batteries
Oil-free machine
IPAF 3a licence type
Non-marking tyres
Suitable for indoor use
Maximum 2 people on the platform
Power to platform
Drivable at full height
Optional extras
SkySentry
SkySiren PCS for Scissor
Operator information
Prior to utilising this equipment, the operator must successfully complete a certified programme in working at heights, such as:
IPAF 3A/3B Mobile Vertical/Mobile Boom Operator Course
IPAF 3A/3B/1B Mobile Vertical/Mobile Boom/Static Boom Operator Course
Full specification
| Working height | 13.8m |
| Safe working load | 320kg |
| Platform/deck size | 2.27m x 1.12m |
| Closed width | 1.19m |
| Closed height | 2.62m |
| Stowed height (guardrails lowered) | 2.09m |
| Outreach | 0 |
| Non-marking tyres | Yes |
| Indoor use | Yes |
| Outdoor use | No |
| Ground condition | Finished |
| Weight | 3200kg |
| Closed length | 2.48m |
| Power | Battery power |
| Manufacturer | Dingli |
| Manufacturer code | JCPT1412PA |
